Draw-wire encoders

D135

  • Encoder freely selectable
  • Precise measuring
  • Movable cable pylon
  • High dynamics
  • Max. measuring length 42,5 m
  • Speed 10 m/s
  • max. linearity ±0,02 %
Analog 0–10 V
EtherNet/IP
CANopen
EtherCAT
Push-pull
TTL / RS422
SAE J1939
SinCos
PROFIBUS DP
PROFINET IO
SSI, binary
BiSS
IO-Link

Draw-wire encoder - perfect for long measuring ranges.

These draw-wire mechanics D135 can be used up to a measuring length of 42.5 meters. This draw-wire mechanics may be combined with the proven Kübler Sendix encoders with incremental or absolute interface, as well as with analog sensors.
With its compact construction, the D135 suits perfectly all measuring tasks from 8 up to 42.5 meters.

Mechanical
Measuring system Draw-wire encoders
Measuring length 8 m
10 m
12 m
15 m
20 m
25 m
30 m
35 m
40 m
42,5 m
Speed 10 m/s
Dimension 135 mm x 135 mm x 318 mm
Working temperature -20 °C ... +90 °C
Protection level IP65
Electrical
max. linearity ±0,02 %
Interfaces Analog 0...10 V
Analog 4–20 mA
EtherNet/IP
CANopen
EtherCAT
Gegentakt
TTL / RS422
SAE J1939
SinCos
Potentiometer output
PROFIBUS DP
PROFINET IO
SSI, binär
BiSS
IO-Link
Power supply 12...30 V DC
Robust
  • The titanium-anodized aluminum housing and the stainless steel wires allow for using the mechanics even in harsh conditions.
  • Wear-free wire exit thanks to special plain bearing guide.
  • Various wire types and wire fastenings.
Versatile
  • High traverse speed and high acceleration.
  • Flexible mounting thanks to fastening tabs or fastening grooves.
  • Various connection possibilities available.
  • Interchangeable encoders (interchangeable installation).
Data sheet

D135

PDF ∼ 1,3 MB | 08.2024
DE
EN
FR
Installation manual

Safety Advice for Draw-wire encoders

Multilingual: German, English, French, Italian
PDF ∼ 160,6 KB | 05.2017

Manual

A50 / B80 / C120 / D135

PDF ∼ 890,5 KB | 05.2024
DE
EN
FR
Safety characteristics

D135 MTTFd

Multilingual: German, English
PDF ∼ 214,8 KB | 06.2019

D135 MTTFd

Multilingual: German, English
PDF ∼ 154,2 KB | 06.2019

Declaration of conformity

A50 / B80 / C120 / D135 CE

Multilingual: German, English, French
PDF ∼ 351,9 KB | 04.2016

Device file

Sendix 58x8 CANopen

ZIP ∼ 63,9 KB | 02.2018

Sendix 58x8 EtherCAT

ZIP ∼ 42,7 KB | 05.2024

Sendix 58x8 PROFIBUS

ZIP ∼ 35,8 KB | 08.2017

Sendix 58x8 PROFINET GSDML

ZIP ∼ 15,2 KB | 09.2016

Sendix F58x8 CANopen

ZIP ∼ 11,2 KB | 10.2014

Sendix M58x8 MT CANopen

ZIP ∼ 678,9 KB | 12.2022

Sendix F58xx - Singleturn EtherNet/IP

ZIP ∼ 15,0 KB | 01.2021

Mechanical CAD / STEP

D135

ZIP ∼ 47,2 MB | 01.2015

Brochures

Solutions for Mobile Automation

PDF ∼ 6,8 MB | 05.2024
DE
EN
FR
Flyer

Portfolio overview Draw-wire encoders

Multilingual: German, English
PDF ∼ 221,1 KB | 11.2019

Accessories

Guide pulley

Guide pulley

With guide pulleys, linear movements can also be directed around obstacles. This not only increases their flexibility but can also compensate for installation tolerances. Idler pulleys can also act to clean off dirt and break ice.

Technical data:
  • Installation angle (anodized aluminum)
  • Guide pulley (plastic POM)
  • Ball bearing (Type 696-2R5)
Scope of delivery:
  • 2 x countersunk screws for side fixing
  • 2 x Allen screws for fixing on a flat surface
8.0000.7000.0045
Mechanical CAD / STEP
8.0000.7000.0045

Extension cable steel

Extension cable steel

With extension cables, the actual measuring range can be used without any loss of resolution. We offer numerous extension cables in our portfolio for this purpose.
5 m 8.0000.7000.0048
0,5 m 8.0000.7000.0051
1 m 8.0000.7000.0052
6,5 m 8.0000.7000.0053
3 m 8.0000.7000.0055

Cables and connectors

M12 Connector with cable ,

M12 Connector with cable ,

Preassembled cable set

CANopen
CANopen-Lift
SAE J1939
Modbus
Power supply
Female connector 5-pin PVC Ø 5,5 mm ± 0,2 mm
5 x 0,25 mm2
05.00.6081.2211.XXXM

Data sheet
M12 cordset, PVC, socket, 5-pin, A-coded, open end
DE EN FR

M12 Connector ,

M12 Connector ,

Field-wireable connector

CANopen
CANopen-Lift
SAE J1939
Modbus
Power supply
Female connector 5-pin
05.B-8151-0/9

Data sheet
M12 socket, 5-pin
DE EN FR

M12 Connector ,

M12 Connector ,

Field-wireable connector

CANopen
CANopen-Lift
SAE J1939
Modbus
Power supply
Female connector 5-pin
05.B-8251-0/9

Data sheet
M12 socket, angled, 5-pin, A-coded
DE EN FR

M12 Connector ,

M12 Connector ,

Field-wireable connector

Analog ±10 V
IO-Link
Power supply
Female connector 4-pin
05.B8141-0

Data sheet
M12 socket, 4-pin, A-coded
DE EN FR

M12 Connector ,

M12 Connector ,

Field-wireable connector

CANopen
CANopen-Lift
SAE J1939
Modbus
Power supply
Female connector 5-pin
8.0000.5116.0000

Data sheet
M12 socket, 5-pin, A-coded
DE EN FR

Cable 5 x 0,14 mm<sup>2</sup>  ,

Cable 5 x 0,14 mm2 ,

Unassembled by the meter

PVC Ø 4,7 mm ± 0,2 mm
5 x 0,14 mm2
8.0000.6300.XXXX
Data sheet
Cable, 5-core, PVC
DE EN FR

Cable 5 x 0,75 mm<sup>2</sup>  ,

Cable 5 x 0,75 mm2 ,

Unassembled by the meter

TPE Ø 7,5 mm ± 0,3 mm
5 x 0,75 mm2
8.0000.6600.XXXX
Data sheet
Cable, 5-core, PE-X
DE EN FR
